Compact Liquid Cooling System

Compact Liquid Cooling System
Compact Liquid Cooling System
Product Code : CLCS 08
Product Description

Compact Liquid Cooling System

With the efforts of our professionals, we are able to manufacture and export an exclusive range of Compact Liquid Cooling System. This system is made from high quality raw materials procured from reliable sources of the industry and cutting edge technology, which ensure high performance at its user end. The entire range of Compact Liquid Cooling System is recognized for its high tensile strength, operational fluency, easy installation and longer service life. Clients can avail this system as per their needs at competitive prices.

Advantages of the Compact Cooling System :

  • Film thickness can be easily adjusted
  • Cooling capacity ranges from 50-1000 kg/hr
  • Reverse inching facility.
  • Easy operating and maintenance.
  • Compact Design for better space utilization.
  • Light weight & stainless steel construction for easy & fast cleaning.
  • Wheel mounted for easy movement.
  • Long life PTFE Coated belt.
  • Spring loaded belt, to ensure equal film thickness.
  • Max. temp. at inlet on belt is 900 Celsius.

Technical specifications





Overall Sizes
Overall Length
Overall Width
Max. feeding height
Overall height

650 mm
60 mm
850 mm

1450 mm
1050 mm
920 mm
1250 mm

3500 mm
1800 mm
1400 mm
1850 mm

Technical Data
Squeezing roll dia.
Cooling roll dia
Width of cooling roll
Max. Container Ht. at Discharge
Roller motor
Speed of roller
Crusher motor
Output Capacity
Cooling water temp. deg. Cel.
Cooling water consumption /min

89 mm
270 mm
300 mm
400 mm
0.5 hp
3 rpm
0.5 hp
50-60 kg/hr
max. 10 deg.
min. 30 lt.

112 mm
550 mm
450 mm
525 mm
1 hp
5 rpm
1 hp
150-200 kg/hr
max. 10 deg.
min. 120 lt.

210 mm
1250 mm
1000 mm
1050 mm
5 hp
8 rpm
2 hp
max. 10 deg.
min. 350 lt.
